Load break switch with visible breaking 4P 125A HA406
EAN
3250613114060
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Architecture
-
Type of orderShort thumb-grip
-
Number of poles4 P
-
Type of pole4 P
-
Type of caseFixed built-in
Functions
-
Reversing switchNo
Configuration
-
Number of modules6
Controls and indicators
-
Motor drive integratedNo
Main electrical features
-
Rated operational voltage Ue380 / 415 V
-
Frequency50 Hz
Voltage
-
Rated insulation voltage800 V
-
Rated impulse withstand voltage8000 V
Electric current
-
Rated operational current in AC21category B125 A
-
Acceptable current rating with AC22 category A125 A
-
Cut off current15 kA
-
Rated current125 A
-
Short-circuit current with gI-gG fuses50 kA
-
Rated short-time withstand current 1s2.5 kA
-
Rated operational current in AC21 category A125 A
-
Acceptable current rating with AC22 category B125 A
-
Rated operational current in AC23 category A63 A
-
Acceptable current rating with AC23 category B63 A
Dimensions
-
Width of installed product108 mm
Power
-
Active power under 380/415 V, 50 Hz45 kW
-
Total power loss under IN17.1 W
-
Power loss per pole at In5.7 W
-
Contact rating with 400 V in AC182 kW
Cover, door
-
InterlockableYes
Installation, mounting
-
Tightening torque6 - 6.6 Nm
-
Fixation typeDIN rail monting or back plate monting
Connection
-
Connection cross-sect. rigid cable50mm² max.
-
Type of connectionwith screw
Equipment
-
Number of auxiliary contacts as normally closed contact0
-
Number of auxiliary contacts as normally open contact0
-
Number of auxiliary contacts as change-over contact0
-
Motor drive optionalNo
Safety
-
REACH conformYes
-
RoHS conformYes
-
Halogen freeNo
Use conditions
-
Operating temperature-20…70 °C
