The Hager 63A Modular Contactor with 2 NO contacts and 230V~ 50Hz coil is designed for reliable switching of heavy loads such as lighting, heating, and motors. Its 63A rating suits residential and commercial control. The DIN-rail modular format saves space, while 2NO contacts ensure clear isolation and straightforward remote control for automation and energy management. Designed for reliable installation in residential and commercial switchboards,suitable for DIN rail mounting.
EAN
3250612401116
Packaging
1 Piece
Hager Modular Contactor 63A with 2NO contacts, 230V~ 50Hz ESC263
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Mechanic accessories for low-voltage components 1 products available -
Auxiliary device for distribution board devices 1 products available
Technical properties
Connection
-
Type of contacts2NO
-
Number of contacts2
-
Cross-section flexible conductor1.5 - 16 mm²
-
Cross-section rigid conductor1.5 - 25 mm²
Electric current
-
Rated current63 A
Capacity
-
Number of modules3
Frequency
-
Frequency50 - 50 Hz
Voltage
-
Rated impulse withstand voltage Uimp4000 V
-
Rated insulation voltage Ui440 V
-
Rated operational voltage Ue400 - 400 V
-
Command voltage AC230 - 230 V
-
Command voltage DC0 - 0 V
Use conditions
-
Operating temperature-10 - 50 °C
-
Storage/transport temperature-40 - 80 °C
Use
-
Category of useAC-7a/AC-7b
Endurance
-
Number of mechanical operations100000
-
Electric endurance in number of cycles30000
Power
-
Total power loss under IN11,50 W
-
Inrush power absorbed62,50 VA
Dimensions
-
Height85 mm
-
Width54 mm
-
Depth60 mm
Equipment
-
Number of NO contacts2
-
Number of NC contacts0
-
With switch for manual switchNo
Architecture
-
Number of poles2
Environmental value
We are committed to improve our environmental performance by reducing our carbon footprint. Learn More
Certifications and documents
Downloads
-
Product image
-
Product datasheet
Hager Product data sheet ESC263
