The Hager modular contactor 40A, 4NC, 230V~50Hz provides reliable switching and isolation for lighting, heating, and motor loads. Four normally-closed poles ensure fail-safe de-energized circuits and coordinated control. Quiet modular design fits DIN rail, saves space in panels, and offers long electrical endurance for residential and commercial automation. Designed for reliable installation in residential and commercial switchboards,suitable for DIN rail mounting.
EAN
3250612401369
Packaging
1 Piece
Hager Modular Contactor 40A 4NC Coil 230V~ 50Hz ESC441
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Mechanic accessories for low-voltage components 1 products available -
Auxiliary device for distribution board devices 1 products available
Technical properties
Connection
-
Type of contacts4NC
-
Number of contacts4
-
Cross-section flexible conductor1.5 - 16 mm²
-
Cross-section rigid conductor1.5 - 25 mm²
Electric current
-
Rated current40 A
Capacity
-
Number of modules3
Frequency
-
Frequency50 - 50 Hz
Voltage
-
Rated impulse withstand voltage Uimp4000 V
-
Rated insulation voltage Ui440 V
-
Rated operational voltage Ue400 - 400 V
-
Command voltage AC230 - 230 V
-
Command voltage DC0 - 0 V
Use conditions
-
Operating temperature-10 - 50 °C
-
Storage/transport temperature-40 - 80 °C
Use
-
Category of useAC-7a/AC-7b
Endurance
-
Number of mechanical operations100000
-
Electric endurance in number of cycles30000
Power
-
Total power loss under IN12,80 W
-
Inrush power absorbed62,50 VA
Dimensions
-
Height85 mm
-
Width54 mm
-
Depth60 mm
Equipment
-
Number of NO contacts0
-
Number of NC contacts4
-
With switch for manual switchNo
Architecture
-
Number of poles4
Environmental value
We are committed to improve our environmental performance by reducing our carbon footprint. Learn More
Certifications and documents
Downloads
-
Product image
-
Product datasheet
Hager Product data sheet ESC441
