Current transformer 3-phase 60A/330mV RJ45 Class 1 pitch 25mm plug-in EC1260CT
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Specific identificaton attributes for Protection
-
Filter Type product3-phase current transformer replacement
Functions
-
Accuracy class1
Dimensions
-
Height80 mm
-
Width76 mm
-
Depth76 mm
-
Height of opening15 mm
-
Width of opening30 mm
Connectivity
-
Type of connectionPlug-in connection
Frequency
-
Frequency47 - 63 Hz
Voltage
-
Rated power-frequency withstand voltage (r.m.s.)3000 V
-
Max. operating voltage720 V
Use conditions
-
Operating temperature-25 - 50 °C
-
Storage/transport temperature-40 - 85 °C
Safety
-
Ingress Protection (IP) classIP20
Electric current
-
Rated primary current (Ipr)60 A
-
Rated continuous thermal current1,2*In
-
Rated short-time thermal current (Ith/1s)60*Ipr
-
Rated dynamic current2.5*Ith
-
Over voltage limiting factorFS 5
Installation, mounting
-
Mounting onDIN rail, Busbar, Cable
Architecture
-
Number of poles3
Environmental value
We are committed to improve our environmental performance by reducing our carbon footprint. Learn More
Certifications and documents
Downloads
-
Product image
-
Product datasheet
Hager Product data sheet EC1260CT
Current Transformer with RJ45 output BGUK 3-Phase 60A/330mV Class 1 pitch 25mm
PDF -
Installation manual
Installation manual en-GB 2018-08-24
PDF2,34 MB -
Declaration of conformity
Declaration
Declaration of conformity International 2022-06-07
PDF446,57 kB
Declaration
Declaration of conformity International 2022-08-23
PDF132,32 kB
Declaration
Declaration of conformity International 2021-09-29
PDF276,98 kB
Declaration
Declaration of conformity International 2021-09-29
PDF269,32 kB
Declaration
Declaration of conformity International 2022-08-23
PDF142,96 kB
Declaration of conformity International 2023-12-20
PDF296,11 kB
Declaration of conformity International 2023-12-20
PDF302,50 kB
