Under voltage release 230V AC MZ206
EAN
3250614562068
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Configuration
-
Number of modules1
Main electrical features
-
Rated operational voltage Ue230 V
-
Type of supply voltageAC
-
Frequency50/60 Hz
Voltage
-
Rated insulation voltage4000 V
-
DC control voltage0 V
-
Command voltage AC230 V
-
Rated operational voltage in DC0 V
Electric current
-
Acceptable current rating with AC115 mA
Dimensions
-
Depth of installed product68 mm
-
Width of installed product17.5 mm
Power
-
Inrush power absorbed3.5 VA
-
Total power loss under IN2 W
Tripping
-
Time of response when opening200 ms
-
Performance voltage / Tripping at Ue35 / 70 %
Standards
-
European directive WEEEconcerned
Use conditions
-
Operating temperature-25…60 °C
-
Air humidity protection95%
-
Storage/transport temperature-40…80 °C
