Weekly time switch 1 channel, 12/24V, digital, 2 modules EG103V
EAN-Nr.
3250612279937
Packaging
1 piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical characteristics
Voltage
-
Rated operational voltage Ue12 - 24 V
Frequency
-
Frequency50 - 60 Hz
Power
-
230 V incandescent and halogen lamp2300 W
Functions
-
Power reserve in years5 y
-
With network synchronisationNo
-
With quartz synchronisationYes
-
Number of function channels1
Equipment
-
Accuracy per day1,50 s
-
With impulse programmeYes
-
Number of channels1
Connection
-
Type of contacts1x changeover
-
Cross-section flexible conductor1 - 16 mm²
-
Cross-section rigid conductor1 - 6 mm²
Settings
-
Daily programmeYes
-
Weekly programmeNo
-
Annual programmeNo
Use conditions
-
Operating temperature-5 - +45 °C
Texts
-
Type of connectionWith screw terminals
-
FunctionKeylock by means of blocking key, With pulse function
Dimensions
-
Height85 mm
-
Width35 mm
-
Depth64 mm
Capacity
-
Number of modules2
Main electrical attributes
-
Minimum interval between 2 switching times1 min
