Moulded Case Circuit Breaker h3 x160 TM FIX 3P3D 100A 18kA CTC HDA100L

EAN
3250613136574
Packaging
1 Piece

You have to log in with your myHager profile to see prices and to order.

Add to a list
Add to a list

Login to create a product list

You need to be logged into your myHager account to create product lists

Create an account Sign in

Moulded Case Circuit Breaker h3 x160 TM FIX 3P3D 100A 18kA CTC

HDA100L

  • Accessories
  • Technical properties
  • Environmental value
  • Documentations
  • More products
Download the data sheet

Complete your system

Optional accessories

  • See more (32)
    • Under voltage coil 8 products available
    • AOB MCCB type A-HI 2 products available
    • Auxil­i­aries contact block 4 products available
    • Shunt release 5 products available
    • Terminal cover 4 products available
    • Handle for power circuit breaker 2 products available

    Complete your system

    • Under voltage coil
    • AOB MCCB type A-HI
    • Auxil­i­aries contact block
    • Shunt release
    • Terminal cover
    • Handle for power circuit breaker
    • Connec­tion Func­tions
    • Auxil­i­aries cable adaptor
    • Locking inter­locking func­tions
    • Phase separ­a­tion func­tions
    • DIN rail adapter
    • HXA051H

      UVR delayed 24V DC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA015H

      Undervoltage release 380-450V AC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA014H

      Undervoltage release 200-240V AC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA055H

      UVR delayed 380-450V AC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA054H

      UVR delayed 220-240V AC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA011H

      Undervoltage release 24V DC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA053H

      UVR delayed 110-120V AC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA013H

      Undervoltage release 100-120V AC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HBA125H

      Electronic earth leakage add-on block 3P 125A Idn adjustable, time delay
      0.00 €  / *
    • HBA127H

      Electronic earth leakage add-on block 3P 125A Sensitivity fix
      0.00 €  / *
    • HXA026H

      Alarm contact low level 1NO+1NC 125V AC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA021H

      Auxiliary contact 1NO+1NC 250V AC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA024H

      Alarm contact 1NO+1NC 250V AC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA025H

      Auxiliary low level 1NO+1NC 125V AC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA003H

      Shunt trip 100-120V AC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA005H

      Shunt trip 380-450V AC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA002H

      Shunt trip 48V DC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA001H

      Shunt trip 24V DC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA004H

      Shunt trip 200-240V AC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HYA027H

      Terminal cover for collar terminal x160 3P
      0.00 €  / *
    • HYA025H

      Terminal cover x160 3P short
      0.00 €  / *
    • HYA023H

      Terminal cover x160 3P spreader
      0.00 €  / *
    • HYA021H

      Terminal cover x160 3P long
      0.00 €  / *
    • HXA031H

      Extended rotary handle x160
      0.00 €  / *
    • HXA030H

      Direct rotary handle x160
      0.00 €  / *
    • HYA014H

      Spreader x160 3P collar
      0.00 €  / *
    • HYA013H

      Extended connection x160 4P collar
      0.00 €  / *
    • HYA005H

      Collar terminal x160 Al 3P
      0.00 €  / *
    • HYA035H

      Connecting kit 3P/4P
      0.00 €  / *
    • HXA039H

      Padlock (x160-P160-x250-P250-x630)
      0.00 €  / *
    • HYA019H

      Interphase barrier x160 3/4P
      0.00 €  / *
    • HYA033H

      DIN Rail adaptator x160 3P/4P
      0.00 €  / *

    Technical properties

    Elec­tric current
    • Rated current
      100 A
    • Rated ulti­mate short-­cir­cuit breaking capa­city Icu under 400 V AC IEC 60947-2
      18 kA
    • Rated ulti­mate short-­cir­cuit breaking capa­city Icu under 240 V AC IEC 60947-2
      25 kA
    • Rated service breaking capa­city Ics under 230 V AC according to IEC 60947-2
      25 kA
    • Rated service breaking capa­city Ics under 400 V AC according to IEC 60947-2
      18 kA
    • Rated current 0°C according to IEC 60947
      120.50 A
    • Rated current 10°C according to IEC 60947
      120.50 A
    • Rated current 15°C according to IEC 60947
      118.10 A
    • Rated current 20°C according to IEC 60947
      115.70 A
    • Rated current 25°C according to IEC 60947
      113.20 A
    • Rated current 30°C according to IEC 60947
      110.70 A
    • Rated current at 35°C according to IEC 60947
      108.10 A
    • Rated current at 40°C according to IEC 60947
      105.50 A
    • Rated current 45°C according to IEC 60947
      102.70 A
    • Rated current 50°C according to IEC 60947
      100 A
    • Rated current 55°C according to IEC 60947
      97.10 A
    • Rated current 5°C according to IEC 60947
      118.10 A
    • Rated current at 60°C according to IEC 60947
      94.10 A
    • Rated current 65°C according to IEC 60947
      91.10 A
    • Rated current 70°C according to IEC 60947
      87.90 A
    Archi­tec­ture
    • Number of poles
      3
    • Control/­op­er­a­tion element
      Toggle
    • Device construc­tion type
      Fixed built-in
    • Neutral posi­tion
      Without neutral
    Trip­ping
    • Response time when opening
      10 ms
    Frequency
    • Frequency
      50 - 60 Hz
    Voltage
    • Rated impulse with­stand voltage Uimp
      8,000 V
    • Rated insu­la­tion voltage Ui
      690 V
    Func­tions
    • Trip unit
      TM F/F
    Power
    • Total power loss under IN
      39 W
    Endur­ance
    • Elec­tric endur­ance in number of cycles
      10,000
    • Number of mech­an­ical oper­a­tions
      20,000
    Safety
    • Ingress Protec­tion (IP) class
      IP4X
    Connec­tion
    • Cross-sec­tion flex­ible conductor
      4 - 70 mm²
    • Cross-sec­tion rigid conductor
      4 - 95 mm²
    Connectivity
    • Type of connec­tion
      Screw terminal
    Settings
    • Thermal protec­tion knob setting xIN
      1, 1
    Dimen­sions
    • Height
      130 mm
    • Width
      75 mm
    • Depth
      68 mm
    Compat­ib­ility
    • Suit­able for DIN Rail
      Yes
    Install­a­tion, mounting
    • Mount­ing-/­Con­nec­tion Posi­tion
      Front
    Main elec­trical attrib­utes
    • Magnetic protec­tion trip time
      0 - 0 ms

    Environmental value

    We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers Learn More

    RoHS conform Yes
    REACh-SVHC free Yes

    Certifications and documents

    Moulded Case Circuit Breaker h3 x160 TM ADJ 3P3D 100A 18kA CTC
    PDF
    14,81 MB
    Hager REACH declaration HDA100L
    PDF
    RoHS report HDA100L
    PDF

    Downloads

    • Product image

      Image HDA100L | Hager

      Product Image HDA100L

    • Product datasheet

      Image Hager Product data sheet HDA100L | Hager

      Hager Product data sheet HDA100L

      Moulded Case Circuit Breaker h3 x160 TM FIX 3P3D 100A 18kA CTC

      PDF

    • Declaration of conformity

      Image EU Declaration of Conformity | Hager

      EU Declaration of Conformity

      Declaration of conformity en-GB 2025-03-20

      PDF
      430,96 kB
      Image UKCA Declaration of Conformity | Hager

      UKCA Declaration of Conformity

      Declaration of conformity en-GB 2025-03-20

      PDF
      435,49 kB
