    • Home
    • Catalogue
    • HAD410
    EAN
    3250613140458
    Packaging
    1 Piece

    Load break switch 4P 100A HAD410

    Login to create a product list

    You need to be logged into your myHager account to create product lists

    Create an account Sign in
    Phase out product: please contact your electrical wholesaler for availability

    Follow-up products :

    HAC410, HAD412

    Load break switch 4P 100A

    HAD410

    • Accessories
    • Technical properties
    • Environmental value
    • Documentations
    Download the data sheet

    Complete your system

    Optional accessories

    • Switch oper­ating shaft 3 products available
    • Auxil­iary contact block 2 products available
    • Door coup­ling handle for switchgear 1 products available
    • Terminal cover 1 products available

    Complete your system

    • Switch oper­ating shaft
    • Auxil­iary contact block
    • Door coup­ling handle for switchgear
    • Terminal cover
    • HZC111

      Shaft extension N°5 150mm LBS 20-125A
      0.00 €  / *
    • HZC113

      Shaft extension N°5 320mm LBS 20-125A
      0.00 €  / *
    • HZC112

      Shaft extension N°5 200mm LBS 20-125A
      0.00 €  / *
    • HZC312

      Auxiliary contact 2C LBS 20-160A
      0.00 €  / *
    • HZC311

      Auxiliary contact 1C+1O LBS 20-160A
      0.00 €  / *
    • HZC011

      Grey handle LBS 100-125A
      0.00 €  / *
    • HZC216

      Terminal shrouds 4P LBS 100A-125A
      0.00 €  / *

    Technical properties

    Elec­tric current
    • Rated current
      100 A
    • Accept­able current rating AC21
      100 A
    • Accept­able current rating AC23 category A
      100 A
    • Rated short-­time with­stand current Icw 1s IEC 60947
      2.75 kA
    • Rated short-­time with­stand current Icw IEC 60947
      2.75 kA
    • Rated condi­tional short-­cir­cuit current Icc with gl-gG fuses
      25 kA
    Archi­tec­ture
    • Control/­op­er­a­tion element
      Short rotary handle
    • Number of poles
      4
    Connec­tion
    • Cross-sec­tion rigid conductor
      70 mm²
    Voltage
    • Rated insu­la­tion voltage Ui
      800 V
    • Rated impulse with­stand voltage Uimp
      8,000 V
    • Rated oper­a­tional voltage Ue
      380 - 415 V
    Power
    • Power loss per pole at In
      4.30 W
    • Total power loss under IN
      17.20 W
    • Rated oper­a­tional power under 400 V AC AC1
      65,000 W
    • Rated oper­a­tional power under 400 V AC AC23
      45,000 W
    Install­a­tion, mounting
    • Nominal tight­ening torque
      4 - 4.4 Nm
    Equip­ment
    • Motor drive optional
      No
    • Number of auxil­iary contacts as change-over contact
      0
    • Number of auxil­iary contacts as normally closed contact
      0
    • Number of auxil­iary contacts as normally open contact
      0
    Use condi­tions
    • Oper­ating temper­ature
      -20 - 70 °C
    Cover, door
    • Inter­lock­able
      Yes
    Safety
    • Ingress Protec­tion (IP) class
      IP20
    Connectivity
    • Type of connec­tion
      Screw terminal
    Func­tions
    • Is reversing switch
      No
    • Version as emer­gency stop install­a­tion
      No
    • Version as main switch
      Yes
    • Version as main­ten­ance/ser­vice switch
      Yes
    • Version as safety switch
      Yes
    • Version as switch discon­nector compact
      Yes
    Capa­city
    • Number of modules
      5.95

    Environmental value

    We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers Learn More

    RoHS conform Yes
    REACh-SVHC free Yes

    Certifications and documents

    Hager REACH declaration HAD410
    PDF
    Hager RoHS report HAD410
    PDF

    Downloads

    • Product image

      Image HAD410 | Hager

      Product Image HAD410

    • Product datasheet

      Image Hager Product data sheet HAD410 | Hager

      Hager Product data sheet HAD410

      Load break switch 4P 100A

      PDF

    • Declaration of conformity

      Image Declaration | Hager

      Declaration

      Declaration of conformity International 2022-04-13

      PDF
      835,39 kB
      Image EU Declaration of conformity | Hager

      EU Declaration of conformity

      Declaration of conformity en-GB 2025-11-21

      PDF
      604,46 kB
