Enclosure,gamma,surface mounting,54 Modules, version France GD318A
EAN
3250612845835
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Side/back panel 1 products available -
Lock system 1 products available -
Accessories/spare parts for terminals 1 products available -
Cover strip 3 products available -
Accessories/spare parts for low-voltage switch technology 1 products available
Complete your system
Technical properties
Installation, mounting
-
Mounting onSurface mounting
Electric current
-
Rated current63 A
Equipment
-
Number of rails3
-
Number of rows3
-
Number of section in width1
-
With lockNo
-
Has neutral terminal blockYes
-
Has earthing terminal blockYes
-
Has mounting plateYes
Capacity
-
Number of modules54
Dimensions
-
Height500 mm
-
Width355 mm
-
Depth103 mm
-
Number of width units18
Cover, door
-
Number of cabinet doors0
-
Number of locks0
-
Door/cover is transparentNo
Materials
-
MaterialPlastic
-
RAL code9010
-
ColourPure white
Safety
-
Impact resistance IKIK05
-
Ingress Protection (IP) classIP30
-
Locking typeWithout lock
Environmental value
We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers Learn More
Certifications and documents
Downloads
-
Product image
-
Installation manual
Installation manual International 2015-07-13
Installation manual International 2022-03-21
PDF3,95 MB -
Declaration of conformity
Declaration of conformity en-GB 2025-03-06
PDF226,00 kB
