Fuse switch disconnector LT size 3 630A for mounting plate, terminal M10 LT350

Name: LT350
Brand: Hager
SKU: 34370-6000

EAN

3250614203503

Packaging

1 Piece

Technical properties
Environmental value
Documentations
More products

Download the data sheet

Technical properties

Rated current

630 A
Rated short-time withstand current Icw 1s IEC 60947

20.40 kA
Acceptable current rating AC22 category B

630 A

Fuse size

NH3

Cross-section flexible conductor

70 - 300 mm²
Cross-section rigid conductor

70 - 300 mm²

Operating temperature

-25 - 55 °C

Nominal tightening torque

20 - 20 Nm
Mounting on

Mounting plate

Frequency

50 - 60 Hz

Total power loss under IN

57 W

Number of mechanical operations

800
Electric endurance in number of cycles

200
Total service life (mechanical and electrical endurance) IEC 60947-3 Table 4

1,000

Rated insulation voltage Ui

1,000 V
Rated impulse withstand voltage Uimp

8,000 V

Ingress Protection (IP) class

IP3X

Height

306 mm
Width

250 mm
Depth

130 mm

Environmental value

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

RoHS conform Yes

REACh-SVHC free Yes

Halogen free Yes
