FIN 2 Gang Switch Plate cw mechs MW • WBQSV2-MW | Hager
Location Australia

  • Better buildings. Better tomorrows.

    • Menu
    Account
    The Hager 24M 2-Row DIN Surface Metal Box (no door) for tidy indoor distribution in residential or light commercial use. 24 modules on 2 rails, 16 conduit inlets for easy wiring. Robust steel (RAL 9002) with IK05 impact resistance and Class I insulation. Surface, screw-mounted, 369×419×71 mm. Rated 230-415 V. Ideal for sub-boards and refurbishments. Designed for reliable installation in residential and commercial switchboards; suitable for DIN rail mounting and compliant electrical distribution.
    EAN
    3250617005524
    Packaging
    10

    Hager 2-Gang 2-Way Switch 16A Flush Mount White Matt Screw Terminals WBQSV2-MW

    Complete your system

    Optional accessories

    • Accessor­ies/s­pare parts for domestic switching devices 2 products available

    Technical properties

    Elec­tric current
    • Rated current
      16 A
    Install­a­tion, mounting
    • Mounting on
      Flush mounting
    Frequency
    • Frequency
      50 - 50 Hz
    Mater­ials
    • Colour
      White
    • Surface finish
      Matt
    • Material
      Polycar­bonate (PC)
    • Treat­ment
      Varnished
    Iden­ti­fic­a­tion
    • Assembly arrange­ment
      Basic element with full cover plate
    Connectivity
    • Mounting type
      Screw mounting
    Controls and indic­ators
    • Number of buttons
      2
    Dimen­sions
    • Built-in depth
      23 mm
    • Built-in depth flush-­mounted boxes
      23 mm
    Safety
    • Impact resist­ance IK
      IK08
    Texts
    • Install­a­tion mode
      For screw fastening
    • Type of connec­tion
      With screw terminals
    • Lighting
      Without lighting (cannot be illu­min­ated)
    • Push button
      No

    Environmental value

    We are committed to improve our environmental performance by reducing our carbon footprint. Learn More

    RoHS conform Yes
    REACh-SVHC free Yes
    Halogen free Yes

    Certifications and documents

    PEP - 2 way switch gallery InterBP with neutral 2 modules (English)
    PDF
    28,95 MB
    REACH declaration WBQSV2-MW
    PDF
    RoHS report WBQSV2-MW
    PDF

    Downloads

    More documentation
