Dimmer 1 channel 300W TYA661AN
EAN
3250616059375
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Architecture
-
Fixing modeREG
Functions
-
Bus module detachableNo
-
Multi-phase modesuitable to switch different external conductors
-
Soft startupbulb-preserving soft startup
Configuration
-
Number of modules4
Controls and indicators
-
With LED indicationYes
-
Indicator lampyes
-
Operationmanual operation also possible without bus, e.g. on building site
-
Manual selection switches / push-buttonsselection switch for manual/bus operation as well as load setting
Main electrical features
-
Frequency50/60 Hz
-
Rated current4 mA
Voltage
-
Auxiliary voltage230 V AC
-
Input voltage230 V AC
-
Operating voltage over bus21…32 V DC
Electric current
-
Bus current consumption (data transfer)< 2.3 mA
Fuse
-
Fuseoverheating protection (display using LEDs)
Dimensions
-
Width of rail mounted device (RMD)4 modules
Power
-
Dimmable conventional transformers300 VA
-
Incandescent bulb power300 W
-
Total power loss under IN320 mW
-
Power dissipation per coil180 mW
-
Electronic transformers300 W
Fluorescent bulbs control
-
Dimmable energy-saving lamps60 W
-
Power lighting fluo lamps60W
LED control
-
Max number of LED/CFL lamps8
-
Dimmable LED lamps60 W
-
Dimmable 230 V retrofit LED lamps60 W
-
Power LED60 W
Incandescent bulbs control
-
230 V incandescent lamps and halogen lamps300 W
Connection
-
Type of loaduniversal
-
Conductor cross-section (flexible)0.75…2.5 mm²
-
Conductor cross-section (rigid)0.75…2.5 mm²
-
Bus coupling unitwith integral bus coupling unit
-
Bus connectionbus connection via connecting terminal
Settings
-
Supported configuration modessystem
Scope of delivery
-
Bus connection includedYes
Equipment
-
Type of dimmerdimming actuator
-
Modular expandabilityNo
-
Dimming principlephase cut-on or cut-off according to load type, self-learning
-
low noisevery low noise
Use
-
Local operation/hand operationYes
Safety
-
Protection index IPIP20
Use conditions
-
Operating temperature-5…45 °C
-
Storage/transport temperature-20…70 °C
Identification
-
Main design lineKNX
