KNX GPS Weather Station New Easy TXE530

EAN
3250615878977
Packaging
1 Piece

Technical properties

Architecture
  • Type of product
    analogic multifunction
Functions
  • Precipitation (Yes/No)
    1 bit
  • Easy link functions
    3 preset limit values for wind alarm
Controls and indicators
  • Control
    for control of shading systems for up to 4 facades
  • Button / push-button
    with programming button
Voltage
  • Auxiliary voltage
    24 V AC/DC
  • Operating voltage over bus
    21…32 V DC
Electric current
  • Rated current (heating incl.)
    80 mA
Dimensions
  • Dimensions (LLxwwxhh)
    96 x 77 x 118mm
Measurement
  • Speed measurement range
    0 / 35 m/s
  • Temperature measurement range
    -30 / 80 °C
  • Measuring range, wind speed
    0…35 m/s
  • Measuring range, wind strengths
    0…35 Bft
Power supply
  • Supply voltage
    24 V AC/DC
Detection
  • Sensor
    with wind, precipitation, twilight, temperature and brightness sensor
Lighting control
  • Brightness measurement range
    0 / 150000 Lux
LED control
  • LED
    with red programming LED
Installation, mounting
  • Installation mode
    for wall and mast assembly ; with pipe clamp for mast fixing
Connection
  • Bus coupling unit
    with integral bus coupling unit
  • Bus connection
    bus connection via connecting terminal
Settings
  • Supported configuration modes
    system, easy
  • Parameterisation
    easy commissioning by means of predefined parameters ; predefined parameters when activating heat protection function or heat generation function
  • Time
    with automatic summer/winter time change-over ; Reception of date, time and location data via GPS signal
Equipment
  • Number of binary inputs
    0
  • Heating
    with heater element for winter operation
Use
  • Differentiation characteristic 3 - Sales
    with integral bus coupling unit
Safety
  • Alarm
    cyclical transmission behaviour for outside temperature, frost alarm, brightness, day/night mode, wind alarms and rain alarm predefined
Use conditions
  • Operating temperature
    -30…50 °C
temperatur
  • Temperature measuring range, linear
    -30…80 °C
Identification
  • Main design line
    KNX
Instructions
  • Information text
    Ensure correct orientation and free-standing installation.
