Weekly time switch EASY, 2 modules TXA022
EAN
3250616040991
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Architecture
-
Bus systemEIB
Functions
-
FunctionFunctions e.g. switching, dimming, blinds, light scenes, heating, operating modes, date, time
Configuration
-
Number of modules2
Controls and indicators
-
Indication / displayLCD display for commissioning
-
Button / push-buttonwith 5 manual operation buttons
Voltage
-
Operating voltage over bus21…32 V DC
-
System supply voltage30V DC via bus
Electric current
-
Bus consumption4 mA
Dimensions
-
Depth of installed product97 mm
-
Height of installed product85 mm
-
Length97 mm
-
Width of installed product36 mm
-
Width of rail mounted device (RMD)2 modules
Power
-
Total power loss under IN0.3 W
-
Dissipated energy in cable1 W
Battery
-
Lithium cell power reserve [years]≈ 5
Materials
-
RAL colourRAL 7035 - Light grey
Connection
-
Conductor cross-section (flexible)1.5…10 mm²
-
Conductor cross-section (rigid)1…6 mm²
-
Bus coupling unitwith integral bus coupling unit
-
Type of connectionwith screw terminals
-
Bus connectionbus connection via connecting terminal
-
Type of connectionwith screw
Settings
-
Number of program steps56
-
Supported configuration modessystem, easy
-
Summer / Winter time changeautomatic
-
Shortest switching time1 mn
-
Type of programmingdigital
-
Astro programNo
Scope of delivery
-
Bus connection includedYes
Equipment
-
Number of outputs2
-
Number of channels2
-
Supply failure reservelithium battery
-
With holidays programYes
-
With random programYes
Use
-
Cycleweekly
-
Differentiation characteristic 1 - Saleswith hinged cover
-
Differentiation characteristic 2 - Saleswith display
-
Differentiation characteristic 3 - Saleswith integrated bus coupling unit
Safety
-
REACH conformNo
-
Keywith programming key
Use conditions
-
Operating temperature0…45 °C
-
Storage/transport temperature-20…70 °C
Identification
-
Main design lineKNX
