Current transformer 600 / 5A SR600
EAN
3250615686008
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Architecture
-
Type of productSingle-phase current converter
Functions
-
Precision class1
Configuration
-
Number of modules4.5
Main electrical features
-
Frequency50/60 Hz
Electric current
-
Maximum current of primary720 A
-
Maximum current of secondary5 A
Dimensions
-
Depth of installed product75 mm
-
Height of installed product70 mm
-
Width of installed product77 mm
-
width of opening35 mm
-
Height of opening40 mm
-
Bar size40 x 10 mm
Power
-
Total power loss under IN0 W
Connection
-
Connection cross-sect. flexible conductor1,5 / 4mm²
-
Connection cross-sect. rigid cable2,5 / 6mm²
-
Type of connectionscrew
Cable
-
Cable diameter35 mm
Use
-
Transformation Ratio600A ; 5A
Safety
-
Protection index IPIP20
-
REACH conformYes
-
RoHS conformYes
Use conditions
-
Operating temperature-25…50 °C
-
Storage/transport temperature-40…80 °C
