Phase out
Analogue ammeter 0-50A indirect reading SM050
EAN
3250615630506
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
This product is unfortunately no longer available. Please contact our Customer Service team on 1300 850 253 for more information. We do have alternative solution that may be suitable
Technical properties
Capacity
-
Number of modules4
Use conditions
-
Operating temperature-25 - 50 °C
-
Storage/transport temperature-40 - 80 °C
Connection
-
Cross-section flexible conductor1 - 6 mm²
-
Cross-section rigid conductor1.5 - 10 mm²
Dimensions
-
Height85 mm
-
Width70 mm
-
Depth54 mm
Measurement
-
Current measurement range0 - 50 A
-
Type of measuring instrumentAnalog
Power
-
Power consumption VA1,10 VA
-
Total power loss under IN1,10 W
Safety
-
Ingress Protection (IP) classIP20
Installation, mounting
-
Mounting onDIN rail
Functions
-
Accuracy class0.015
Voltage
-
Rated insulation voltage Ui2000 V
Frequency
-
Frequency45 - 65 Hz
Environmental value
We are committed to improve our environmental performance by reducing our carbon footprint. Learn More
Certifications and documents
Downloads
-
Product image
-
Product data sheet
UK_MD_TDS_AnalogueVoltmereammeter
Product data sheet en-GB 2024-03-22
PDF86,21 kB
