Flexible slotted panel trunking Polyamid halogenfree 30mm Länge=0,5m light grey M5692
EAN
4012740104395
Packaging
40 PCEs
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Architecture
-
FlexibleYes
Configuration
-
Side wall configurationSlotted
Electric current
-
Current leak stableYes
Dimensions
-
Length500 mm
-
Slot width8 mm
-
Tongue width4.5 mm
Cover, door
-
Lid shapenone
Materials
-
Colourlight grey
-
MaterialPolyamid (PA)
-
Material groupplastic
-
Type of surface treatmentuntreated
Installation, mounting
-
Base punchingWith base punching
-
Fixing typebottom punching
Cable
-
Number of wires 1,5 mm² - 40% filling degree46
-
Internal/useful cross section379 mm²
-
Number of wires 2,5 mm² - 40% filling degree30
-
Number of wires 1,0 mm² - 40% filling degree57
Standards
-
European directive RoHsvoluntary compliance
-
UL 94 classificationV0
Safety
-
REACH conformYes
-
RoHS conformYes
-
Halogen freeYes
temperatur
-
Ambient temperature-25…90 °C
