Motorized transfer switch 4P 400A HIB440M
EAN
3250613191382
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Architecture
-
Type of orderNot applicable
-
Number of poles4 P
-
Type of pole4 P
-
Type of caseFixed built-in
Functions
-
Reversing switchYes
Controls and indicators
-
Motor drive integratedYes
Main electrical features
-
Rated operational voltage Ue380 / 415 V
-
Frequency50/60 Hz
Voltage
-
Rated insulation voltage1000 V
-
Rated impulse withstand voltage12000 V
Electric current
-
Rated operational current in AC21category B400 A
-
Acceptable current rating with AC22 category A400 A
-
Rated current400 A
-
Short-circuit current with gI-gG fuses50 kA
-
Rated short-time withstand current 1s8 kA
-
Rating current 10°C according to IEC 60947400 A
-
Rating current 15°C according to IEC 60947400 A
-
Rating current 20°C according to IEC 60947400 A
-
Rating current 25°C according to IEC 60947400 A
-
Rating current 30°C according to IEC 60947400 A
-
Rating current 35°C according to IEC 60947400 A
-
Rating current 40°C according to IEC 60947400 A
-
Rating current 45°C according to IEC 60947360 A
-
Rating current 5°C according to IEC 60947400 A
-
Rating current 50°C according to IEC 60947360 A
-
Rating current 55°C according to IEC 60947320 A
-
Rating current 60°C according to IEC 60947320 A
-
Rating current 65°C according to IEC 60947280 A
-
Rating current 70°C according to IEC 60947280 A
-
Rated operational current in AC21 category A400 A
-
Acceptable current rating with AC22 category B400 A
-
Rated operational current in AC23 category A400 A
-
Acceptable current rating with AC23 category B400 A
-
Conventional thermal current under enclosure at 40°C400 A
Power
-
Total power loss under IN60.4 W
-
Power loss per pole at In15.1 W
-
Contact rating with 400 V in AC1263 kW
Cover, door
-
InterlockableYes
Connection
-
Type of connectionTerminal
Equipment
-
Number of auxiliary contacts as normally closed contact0
-
Number of auxiliary contacts as normally open contact1
-
Number of auxiliary contacts as change-over contact0
-
Motor drive optionalNo
Standards
-
Standard textIEC 60947-3 ; IEC 60947-6
-
European directive WEEEconcerned
Safety
-
Protection index IPIP00
Use conditions
-
Altitude2000 m
-
Storage/transport temperature-40…70 °C
