Hager Modular Contactor 40A 3NO 230V AC 50Hz: reliably switches and controls circuits in residential and commercial boards. Three normally open poles and 40A rating handle lighting, heating, and motor loads. 230V AC coil enables direct mains control. DIN-rail modular design for quick installation and compact panel integration. Suitable for DIN rail mounting and compliant electrical distribution applications.
EAN
3250612401253
Packaging
1 Piece
Hager Modular Contactor 40A 3NO 230V AC 50Hz ESC340
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Mechanic accessories for low-voltage components 1 products available -
Auxiliary device for distribution board devices 1 products available
Technical properties
Connection
-
Type of contacts3NO
-
Number of contacts3
-
Cross-section flexible conductor1.5 - 16 mm²
-
Cross-section rigid conductor1.5 - 25 mm²
Electric current
-
Rated current40 A
-
Acceptable current rating AC325 A
Capacity
-
Number of modules3
Frequency
-
Frequency50 - 50 Hz
Voltage
-
Rated impulse withstand voltage Uimp4000 V
-
Rated insulation voltage Ui440 V
-
Rated operational voltage Ue400 - 400 V
-
Command voltage AC230 - 230 V
-
Command voltage DC0 - 0 V
Use conditions
-
Operating temperature-10 - 50 °C
-
Storage/transport temperature-40 - 80 °C
Use
-
Category of useAC-7a/AC-7b
Endurance
-
Number of mechanical operations100000
-
Electric endurance in number of cycles30000
Power
-
Total power loss under IN11,10 W
-
Inrush power absorbed62,50 VA
Dimensions
-
Height85 mm
-
Width54 mm
-
Depth60 mm
Equipment
-
Number of NO contacts3
-
Number of NC contacts0
-
With switch for manual switchNo
Architecture
-
Number of poles3
Environmental value
We are committed to improve our environmental performance by reducing our carbon footprint. Learn More
Certifications and documents
Downloads
-
Product image
-
Product datasheet
Hager Product data sheet ESC340
Contactor 40A, 3NO, 230V~50Hz
PDF -
Product data sheet
UK_MD_TDS_Contactors.pdf
Technical data sheet including characteristics for Contactors and Override Contactors.
PDF197,47 kB -
