Yearly time switch 4 channels, digital, 4 modules EG493E
EAN
3250612279838
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Phase out product: please contact your electrical wholesaler for availability
Technical properties
Frequency
-
Frequency50 - 60 Hz
Power
-
230 V incandescent and halogen lamp1500 W
Functions
-
Power reserve in years5 y
-
With network synchronisationNo
-
With quartz synchronisationYes
-
Number of function channels4
Equipment
-
Accuracy per day0,20 s
-
With impulse programmeYes
-
Number of channels4
Connection
-
Cross-section flexible conductor0.75 - 2.5 mm²
-
Cross-section rigid conductor0.75 - 2.5 mm²
Settings
-
Daily programmeNo
-
Weekly programmeNo
-
Annual programmeYes
Use conditions
-
Operating temperature-10 - 50 °C
Texts
-
Type of connectionWith quickconnect plug-in terminals
-
FunctionWith pulse function, Keylock via PIN, Presence simulation, With operating hours meter
Dimensions
-
Height90 mm
-
Width70 mm
-
Depth65 mm
Capacity
-
Number of modules4
Main electrical attributes
-
Minimum interval between 2 switching times1 min
