Yearly time switch 2 channels, digital, 4 modules EG293B
EAN
3250612279821
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Architecture
-
Fixing modeDin-Rail
Functions
-
Number of function channels2
-
Multi-phase modesuitable for multi-phase mode
-
FunctionPresence simulation ; Keylock via PIN code ; with operating hours meter ; with pulse function
Configuration
-
Switch mode2 x change-over contact
-
Number of modules4
Controls and indicators
-
Indication / displayLC display with illumination
Main electrical features
-
Rated operational voltage Ue230 V
-
Frequency50/60 Hz
Voltage
-
Operating voltage230 V~
Dimensions
-
Depth of installed product69 mm
-
Height of installed product90 mm
-
Width of installed product70 mm
-
Width of rail mounted device (RMD)4 modules
Power
-
Power consumed2 VA
-
Total power loss under IN2 W
-
Loss power at full load≈ 2 W
Measurement
-
Running accuracy± 0.2 s/day
Battery
-
Power reserve [years]≈ 5 a
-
Lithium cell power reserve [years]≈ 5
-
Battery / storage batterywith lithium coin cell battery type: CR2450
Incandescent bulbs control
-
Max. power with incandescent lamps1500 W
-
230 V incandescent lamps and halogen lampsmax. 1500 W
Installation, mounting
-
Mounting typedin-Rail
-
Installation modefor mounting on DIN rail
Connection
-
Connection cross-sect. flexible conductor0,75 / 2,5mm²
-
Connection cross-sect. rigid cable0,75 / 2.5mm²
-
Conductor cross-section (flexible)0.75…2.5 mm²
-
Conductor cross-section (rigid)0.75…2.5 mm²
-
Number of contacts2
-
Type of contacts2 changeover + 2NO
-
Type of connectionwith QuickConnect plug-in terminals
-
Contactwith potential-free switching contact
-
Type of connectionquick connect
Settings
-
Number of program steps300
-
Summer / Winter time changeautomatic
-
Shortest switching time1 mn
-
Type of programmingdigital, with programmation key
-
Programming cycleyearly
-
Programswith random programme ; holiday programme with date activation
-
ProgrammingProgramming possible without mains voltage
-
Timewith automatic summer/winter time change-over
Equipment
-
Number of channels2
-
Number of switching times for on/off300
-
Supply failure reserve5 years
-
With holidays programYes
Use
-
Cycleyearly
Safety
-
Protection index IPIP20
-
REACH conformYes
-
RoHS conformYes
-
Keywith programming key
Use conditions
-
Operating temperature-10…50 °C
-
Working accuracy+ 0,2 s / 24h
-
Storage/transport temperature-20…70 °C
Identification
-
Main design lineLight control
