Auxiliary contact for RCCB 2(1C+1O) 6A 240V AC CZ001
EAN
3250611860013
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Architecture
-
Fixing modeClipped
Configuration
-
Number of modules1
Main electrical features
-
Rated operational voltage Ue230 / 440 V
-
Frequency50 Hz
Voltage
-
Rated insulation voltage500 V
-
Rated operational voltage in DC12 / 250 V
Electric current
-
Acceptable current rating with AC16 A
-
Rated current6 A
-
Imin = f (U = 230 V AC)6 A
-
Imin = f (U = 230 V DC)0.6 A
-
Imin=f(U=400V AC) for power circuit3 A
Dimensions
-
Width of installed product18 mm
Power
-
Total power loss under IN0.1 W
Endurance
-
Electric endurance in number of cycles6000
-
Number of mechanical operations12000
Installation, mounting
-
Tightening torque1,2Nm
-
Factory fittedNo
Connection
-
Connection cross-sect. flexible conductor4mm²
-
Connection cross-sect. rigid cable6mm²
-
Type of contactsauxiliary contact 1NC+1N0 alarm contact 1NC+1NO
-
Type of connectionwith screw
Equipment
-
Quantity of NC contacts1
-
Quantity of NO contacts1
-
Quantity of INV contacts0
Safety
-
Halogen freeNo
Use conditions
-
Operating temperature-25…60 °C
-
Air humidity protection95% / 80°C
-
Storage/transport temperature-40…80 °C
