Sm.distr.,VD/IC²,surface,1row,18M,IP40,MS-terminals,AUS,N+PE,white door VD118PT
EAN
3250616467453
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Functions
-
With a pipe-in leadYes
Configuration
-
Number of modules18
Main electrical features
-
Nominal voltage400 V
Electric current
-
Rated current80 A
Dimensions
-
Depth of installed product91 mm
-
Internal depth72 mm
-
Height of installed product200 mm
-
Width of installed product400 mm
-
Width in division units18
Cover, door
-
Identification od protection index40
-
InterlockableNo
-
Number of keylock of the door0
-
Cover typeClosed (plain)
-
Door lockingwithout
-
Door leavesingle
-
Cover typeDoor
-
Transparent cover or doorNo
Materials
-
Colourwhite
-
RAL colourRAL 9010 - Pure white
-
Materialplastic
-
Type of surface treatmentuntreated
Installation, mounting
-
Suitable for outdoor useNo
Settings
-
Enclosure typeDistributor empty cabinet
Equipment
-
Number of rows1
-
Quantity of section in width1
-
Quantity of rails1
-
Can be accessorizedYes
-
Number of openings for flange plates0
-
Extension possibleNo
Standards
-
GWT Glow wire test650 °C
Safety
-
Protection classisol.class II
Use conditions
-
Operating temperature-25…40 °C
