Cartridge N-PE Uc 260V In 20kA Imax 100kA Up 1,5kV SPB010N
EAN
3250615515315
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Configuration
-
Number of modules1
Controls and indicators
-
Indicator lampOptic
Main electrical features
-
Rated operational voltage Ue240 / 415 V
Voltage
-
Maximum continuous operating voltage Uc264 V
Dimensions
-
Depth of installed product58.2 mm
-
Height of installed product89.8 mm
Electrical specifications
-
Short-circuit breaking capacity (Isccr)25 kA
Installation, mounting
-
Tightening torque3
Connection
-
Connection cross-section of input and output with screws, for massive conductors1.5 / 35 mm²
-
Connection cross section of access and exit with screws, for flexible conductor1.5 / 25 mm²
Standards
-
Test class IEC61643-11 / VDE0675-6-11T2
-
European directive WEEEconcerned
Safety
-
REACH conformYes
-
RoHS conformYes
-
Halogen freeYes
Use conditions
-
Operating temperature-40…80 °C
