Insulated prong busbar 1P 80A 16mm² 9C for RCBO KB181G1
EAN
3250613730314
Packaging
20 PCEs
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Architecture
-
Number of poles1 P
Configuration
-
Number of modules13
Voltage
-
Rated impulse withstand voltage4 kV
Electric current
-
Rated current80 A
Dimensions
-
Length228 mm
-
Pitch17.8 mm
Power
-
Total power loss under IN1.2 W
Power supply
-
Number of phases for the power supply1 phase
Installation, mounting
-
Suitable to a device with an auxiliaryNo
Connection
-
Connection cross-sect. rigid cable16mm²
-
Suitable for product with neutral busbarNo
-
Connector typebusbar prong
Equipment
-
Number of connections9 C
-
Number of appliances to build in13
Standards
-
European directive RoHsvoluntary compliance
Safety
-
REACH conformYes
-
RoHS conformYes
Use conditions
-
InsulatedYes
