Insulated busbar 1P 63A prong 10mm² brown 13M KB163P
EAN
3250613720018
Packaging
50 PCEs
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Architecture
-
Number of poles1 P
-
Type of pole1 P
Configuration
-
Number of modules13
Compatibility
-
Intended for the compatible referencesModular devices
Main electrical features
-
Rated operational voltage Ue415 V
Voltage
-
Max operating voltage230 V
-
Rated impulse withstand voltage4 kV
Electric current
-
Rated current63 A
Dimensions
-
Length228 mm
-
Pitch17.8 mm
-
Fixation distance in module steps1
Power supply
-
Number of phases for the power supply1 phase
Installation, mounting
-
Suitable to a device with an auxiliaryNo
Connection
-
Connection cross-sect. rigid cable10mm²
-
Suitable for product with neutral busbarNo
-
Connector typebusbar prong
-
Type of connectionwith screw
Equipment
-
Number of appliances to build in13
Safety
-
REACH conformYes
-
RoHS conformYes
Use conditions
-
InsulatedYes
