Fuse carrier 1P 32A 690V L38 1M with signal light LS531
EAN-Nr.
3250614123801
Packaging
12 Pieces
Login to create a product list
You need to be logged into your myHager account to create product lists
No longer available
Complete your system
Optional accessories
-
Mechanic accessories for low-voltage components 1 products available
Technical characteristics
Dimensions
-
Height83 mm
-
Width18 mm
-
Depth75 mm
Architecture
-
Number of poles1
Electric current
-
Rated current32 A
Capacity
-
Number of modules1
Use conditions
-
Operating temperature-5 - 50 °C
Installation, mounting
-
Nominal tightening torque2,20 - 2,20 Nm
-
Mounting onDIN rail
Power
-
Total power loss under IN3,70 W
Voltage
-
Rated insulation voltage Ui690 V
-
Type voltage supplyAC
Safety
-
Ingress Protection (IP) classIP20
Connection
-
Cross-section of input and output with screws, for flexible conductors0,75 - 16,0 mm²
-
Cross-section of input and output with screws, for massive conductors1 - 25 mm²
Fuse
-
Fuse size10 x 38
Cover, door
-
InterlockableYes
