Insulated busbar 1P 100A fork 20mm² 57M KD190B

EAN-Nr.
3250613740481
Packaging
1 piece

You have to log in with your myHager profile to see prices and to order.

Add to a list
Add to a list

Login to create a product list

You need to be logged into your myHager account to create product lists

Create an account Sign in

Insulated busbar 1P 100A fork 20mm² 57M

KD190B

  • Technical characteristics
  • Environmental value
  • Documentations
  • More products

Technical characteristics

Elec­tric current
  • Rated current
    100 A
Archi­tec­ture
  • Number of poles
    1
Dimen­sions
  • Length
    1000 mm
Voltage
  • Rated impulse with­stand voltage Uimp
    4000 V
  • Rated oper­a­tional voltage Ue
    415 - 415 V
Connec­tion
  • Cross-sec­tion rigid conductor
    20 mm²
  • Connect­or/plug type
    Phase busbar with fork
Capa­city
  • Number of modules
    57

Environmental value

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

RoHS conform Yes
REACh-SVHC free Yes

Certifications and documents

Hager REACH declaration KD190B
PDF
Hager RoHS report KD190B
PDF

Downloads

  • Image KD190B | Hager

    Product Image KD190B

  • Declaration of conformity

    Image Declaration of conformity en-GB 2025-10-20 | Hager

    Declaration of conformity en-GB 2025-10-20

    PDF
    839,22 kB
    Image Declaration of conformity en-GB 2025-10-20 | Hager

    Declaration of conformity en-GB 2025-10-20

    PDF
    860,43 kB
