Building automation

Push-button module 1gang, intg temp. sensor+bus coupl. unit,KNX-S.1/B.3/B.7 80141180

Name: 80141180
Brand: Hager
SKU: 80141180P1

EAN-Nr.

3250617153768

Packaging

1 piece

Accessories
Technical characteristics
Environmental value
Documentations
More products

Complete your system

Must-have accessories

See all (5)

80960299

Cover f. 1gang f. push-b. module, clearlens, S.1/B.3/B.7, p.white, matt, plastic

80960285

Cover for 1gang for push-button module, clearlens, S.1/B.3/B.7, ant., matt

80960282

Cover for 1gang for push-button module, clearlens, S.1/B.3/B.7, white glossy

80960289

Cover for 1gang for push-button module, clearlens, S.1/B.3/B.7, p. white glossy

Referenced by 2 products available

Technical characteristics

Mounting on

Flush mounting

Operating temperature

-5 - 45 °C

Bus current consumption data transfer

10 mA

With room temperature controller

No

Built-in depth

31 mm
Built-in depth flush-mounted boxes

34 mm
Height

71 mm
Width

71 mm
Depth

42 mm

Number of actuation points

2

With LED indication

Yes

Colour

Light grey
RAL code

7035
Material

Metal, Plastic

Has labelling field

No

With display

No

Function

Function for manual interruption of automatic functions already triggered
Protection

With dismantling protection
Temperature

Integrated temperature sensor with output of the measured values via object

Environmental value

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

RoHS conform Yes
