Feed-through terminal-neutral, 70mm², 1000V/192A, screw connection KXB70NH
EAN
3250613942212
Packaging
20 Pieces
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Labelling material 1 products available
Technical properties
Electric current
-
Rated current179 A
Dimensions
-
Height98.60 mm
-
Width96 mm
-
Depth24 mm
Installation, mounting
-
Mounting onDIN rail
Connection
-
Cross-section flexible conductor6 - 70 mm²
-
Cross-section rigid conductor95 mm²
Materials
-
ColourBlue
-
MaterialPolyamide (PA)
Connectivity
-
Type of connectionScrew terminal
Environmental value
We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers Learn More
Certifications and documents
Downloads
-
Product image
-
Declaration of conformity
Declaration
Declaration of conformity International 2022-08-29
PDF194,57 kB
Declaration
Declaration of conformity International 2022-11-16
PDF265,19 kB
