Load break switch 4P 1250A • HA462 | Hager
Location Ireland

  • Better buildings. Better tomorrows.

    • Menu
    Account
    EAN
    3250613119713
    Packaging
    1 Piece

    Load break switch 4P 1250A HA462

    Complete your system

    Optional accessories

    • Terminal cover 1 products available
    • Auxil­iary contact block 1 products available
    • Switch oper­ating shaft 2 products available
    • Door coup­ling handle for switchgear 2 products available

    Technical properties

    Elec­tric current
    • Rated current
      1,250 A
    • Rated short-­time with­stand current Icw IEC 60947
      50 kA
    • Accept­able current rating AC21
      1,250 A
    • Accept­able current rating AC21 category A
      1,250 A
    • Accept­able current rating AC21 category B
      1,250 A
    • Accept­able current rating AC22 category A
      1,250 A
    • Accept­able current rating AC22 category B
      1,250 A
    • Accept­able current rating AC23 category A
      1,000 A
    • Accept­able current rating AC23 category B
      1,000 A
    • Rated short-­cir­cuit making capa­city Icm under 415 V AC according to IEC 60947-3
      66 kA
    • Rated short-­time with­stand current Icw 1s IEC 60947
      50 kA
    Archi­tec­ture
    • Number of poles
      4
    • Control/­op­er­a­tion element
      Long rotary handle
    • Device construc­tion type
      Fixed built-in
    • Type of pole
      4P
    Dimen­sions
    • Height
      360 mm
    • Width
      229 mm
    • Depth
      492 mm
    Cover, door
    • Inter­lock­able
      Yes
    Safety
    • Ingress Protec­tion (IP) class
      IP00
    Connec­tion
    • Cross-sec­tion rigid conductor
      4x 185 mm²
    • Cross-sec­tion flex­ible conductor
      4x 185 mm²
    Voltage
    • Rated insu­la­tion voltage Ui
      1,000 V
    • Rated impulse with­stand voltage Uimp
      12,000 V
    • Rated oper­a­tional voltage Ue
      380 - 415 V
    Power
    • Power loss per pole at In
      85 W
    • Total power loss under IN
      255 W
    • Rated oper­a­tional power under 400 V AC AC1
      822,000 W
    • Rated oper­a­tional power under 400 V AC AC23
      562,000 W
    Controls and indic­ators
    • Motor drive integ­rated
      No
    Use condi­tions
    • Oper­ating temper­ature
      -20 - 70 °C
    Frequency
    • Frequency
      50 - 60 Hz
    Func­tions
    • Is reversing switch
      No
    • Version as emer­gency stop install­a­tion
      No
    • Version as main switch
      Yes
    • Version as main­ten­ance/ser­vice switch
      Yes
    • Version as safety switch
      Yes
    • Version as switch discon­nector compact
      Yes
    Equip­ment
    • Motor drive optional
      No
    • Number of auxil­iary contacts as change-over contact
      0
    • Number of auxil­iary contacts as normally closed contact
      0
    • Number of auxil­iary contacts as normally open contact
      0
    Install­a­tion, mounting
    • Nominal tight­ening torque
      40 - 45 Nm

    Environmental value

    We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers Learn More

    RoHS conform Yes
    REACh-SVHC free Yes

    Certifications and documents

    PEP - Load break switch 4P 630A (English)
    PDF
    369,67 kB
    REACH declaration HA462
    PDF
    RoHS report HA462
    PDF
