Polyester enclosure, Orion.Plus, glazed door 500x300x200 mm FL259B

EAN
3250610670927
Packaging
1 Piece

You have to log in with your myHager profile to see prices and to order.

Add to a list
Add to a list

Login to create a product list

You need to be logged into your myHager account to create product lists

Create an account Sign in

Polyester enclosure, Orion.Plus, glazed door 500x300x200 mm

FL259B

  • Accessories
  • Technical properties
  • Environmental value
  • Documentations
  • More products
Download the data sheet

Complete your system

Optional accessories

  • See more (37)
    • Mounting plate for distri­bu­tion board 4 products available
    • Vent­il­ator for enclosure 4 products available
    • Distrib­utor assembly for serial built-in device 3 products available
    • Lock system 5 products available
    • Door/­op­er­ating panel 2 products available
    • DIN rail 2 products available

    Complete your system

    • Mounting plate for distri­bu­tion board
    • Vent­il­ator for enclosure
    • Distrib­utor assembly for serial built-in device
    • Lock system
    • Door/­op­er­ating panel
    • DIN rail
    • Key for enclos­ures/cab­inets
    • Heater for enclosure
    • Insert for lock system
    • Blanking plate for enclosure
    • Mounting accessories
    • Accessor­ies/s­pare parts for low-voltage switch tech­no­logy
    • Accessor­ies/s­pare parts for earthing and light­ning
    • Cover strip
    • FL474A

      Steel mounting plate, Orion.Plus, 480x243 mm
      0.00 €  / *
    • FL407A

      Steel mounting plate, Orion.Plus, 480x243 mm
      0.00 €  / *
    • FL424A

      Insulated mounting plate, Orion.Plus, 435x245 mm
      0.00 €  / *
    • FL311A

      Fixed steel mounting plate, Orion.Plus, 187x145 mm
      0.00 €  / *
    • FL216Z

      Fan, quadro.system, 67W 520m3/h
      0.00 €  / *
    • FL214Z

      Fan, quadro.system, 32W 240 m3/h
      0.00 €  / *
    • FL212Z

      Fan, quadro.system, 20W 115 m3/h
      0.00 €  / *
    • FL210Z

      Fan, quadro.system, 20W 57 m3/h
      0.00 €  / *
    • FL981A

      Chassis kit MCB, orion plus 3x12M 500x300 mm +S
      0.00 €  / *
    • FL991A

      MCB complete kit, Orion.Plus, 3x12M, 450x300 mm, System C
      0.00 €  / *
    • FL361A

      Kit system MCB, Orion.Plus, 150x300 mm
      0.00 €  / *
    • FL96Z

      Triangular lock plus handle, Orion.Plus
      0.00 €  / *
    • FL95Z

      Pair leave inserts, Orion.Plus, 3 mm
      0.00 €  / *
    • FL93Z

      Pair triangle insert, Orion.Plus, 8 mm
      0.00 €  / *
    • FL80Z

      Pair square key inserts, Orion.Plus, 8 mm
      0.00 €  / *
    • FL82Z

      Pair square key inserts, Orion.Plus, 6 mm
      0.00 €  / *
    • FL547A

      Steel inner door, Orion.Plus steel, 500x300 mm
      0.00 €  / *
    • FL644A

      Polyester inner door, Orion.Plus polyester, 500x300 mm
      0.00 €  / *
    • FL492A

      Clamp bracket, Orion.Plus, W300 mm
      0.00 €  / *
    • FL462A

      Functional uprights, Orion.Plus, H500 mm
      0.00 €  / *
    • FL99Z

      Triangular key, Orion.Plus, RAL7046
      0.00 €  / *
    • FL259Z

      Thermostat, quadro.system, 10 A 230 V AC
      0.00 €  / *
    • FL254Z

      Heaters, quadro.system, 45 W 230 V AC/DC
      0.00 €  / *
    • FL255Z

      Heaters, quadro.system, 80 W 230 V AC/DC
      0.00 €  / *
    • FL256Z

      Heaters, quadro.system, 150 W 230 V AC/DC
      0.00 €  / *
    • FL98Z

      Pair inserts for key and sealing handle, Orion.Plus
      0.00 €  / *
    • FL97Z

      Pair leave inserts, Orion.Plus, 3 mm
      0.00 €  / *
    • FL94Z

      Pair triangle insert, Orion.Plus, 8 mm
      0.00 €  / *
    • FL81Z

      Pair square key inserts, Orion.Plus, 8 mm
      0.00 €  / *
    • FL77Z

      Insert lock for rotary handle, Orion.Plus, 6x6 mm
      0.00 €  / *
    • FL711E

      Insulated front panel, Orion.Plus, 150x300 mm
      0.00 €  / *
    • FL672E

      Sliding guides, Orion.Plus, L350 mm
      0.00 €  / *
    • FL450A

      Fixing bracket for mounting plate, Orion.Plus
      0.00 €  / *
    • FL863Z

      Wall ins. fixing brackets, Orion.Plus polyester
      0.00 €  / *
    • FL85Z

      Wall steel fixing brackets, Orion.Plus steel
      0.00 €  / *
    • FL874A

      Ground wire kit, Orion.Plus
      0.00 €  / *
    • FL871Z

      Blanking strips 4 Mod, Quadro.Plus, 6 pieces
      0.00 €  / *

    Technical properties

    Dimen­sions
    • Height
      500 mm
    • Width
      300 mm
    • Depth
      200 mm
    • Thick­ness of side­wall
      3 mm
    Safety
    • Ingress Protec­tion (IP) class
      IP66
    • Protec­tion class
      Isol­a­tion class II
    • Locking type
      3-Side 7 mm, Key lock
    • Impact resist­ance IK
      IK08
    Equip­ment
    • Number of flange plate open­ings
      0
    • Number of rows
      3
    Install­a­tion, mounting
    • Mounting on
      Surface mounting
    • Suit­able for outdoor usage
      Yes
    Mater­ials
    • Colour
      Light grey
    • RAL code
      7035
    • Treat­ment
      Untreated
    • Material
      Glass rein­forced poly­ester
    Cover, door
    • Number of cabinet doors
      1
    • Number of locks
      2
    • Door/­cover is trans­parent
      Yes
    Elec­tric current
    • Rated current
      125 A

    Environmental value

    We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers Learn More

    RoHS conform Yes

    Certifications and documents

    Hager REACH declaration FL259B
    PDF
    Hager RoHS report FL259B
    PDF

    Downloads

    • Product image

      Image FL259B | Hager

      Product Image FL259B

    • Product datasheet

      Image Hager Product data sheet FL259B | Hager

      Hager Product data sheet FL259B

      Polyester enclosure, Orion.Plus, glazed door 500x300x200 mm

      PDF

    • BIM Revit objects

      Image Range : Orion Plus.Enclosure - IP66 - Class II - Depth 200 mm - English - Hosted family - REVIT Family 2020 - V2022 | Hager

      Range : Orion Plus.Enclosure - IP66 - Class II - Depth 200 mm - English - Hosted family - REVIT Family 2020 - V2022

      BIM Revit objects en-GB 2024-03-22

      RFA
      1,86 MB
      Image Range : Orion Plus.Enclosure - IP66 - Class II - Depth 200 mm - English - Non hosted family - REVIT Family 2020 - V2022 | Hager

      Range : Orion Plus.Enclosure - IP66 - Class II - Depth 200 mm - English - Non hosted family - REVIT Family 2020 - V2022

      BIM Revit objects en-GB 2024-03-22

      RFA
      1,91 MB

    • Declaration of conformity

      Image Declaration | Hager

      Declaration

      Declaration of conformity International 2022-07-06

      PDF
      195,93 kB
      Image Declaration | Hager

      Declaration

      Declaration of conformity International 2022-02-24

      PDF
      818,77 kB
