Steel enclosure, Orion.Plus, glazed door 650x400x200 mm FL167A
EAN
3250610670729
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Distributor assembly for serial built-in device 4 products available -
Door/operating panel 2 products available -
Ventilator for enclosure 4 products available -
Heater for enclosure 6 products available -
Thermostat/hygrostat (switchgear cabinet) 1 products available -
See more 30 other products available
Complete your system
-
FL312AFixed steel mounting plate, Orion.Plus, 287x145 mm
-
FL314AAdjustable steel mounting plate, Orion.Plus, 234x145 mm
-
FL322AFixed steel mounting plate, Orion.Plus, 287x195 mm
-
FL324AAdjustable steel mounting plate, Orion.Plus, 604x195 mm
-
FL412ASteel mounting plate, Orion.Plus, 630x343 mm
-
FL426AInsulated mounting plate, Orion.Plus, 585x345 mm
-
FL476ASteel mounting plate, Orion.Plus, 630x343 mm
Technical properties
Dimensions
-
Height650 mm
-
Width400 mm
-
Depth200 mm
-
Thickness of sidewall1.20 mm
Safety
-
Ingress Protection (IP) classIP65
-
Protection classIsolation class I
-
Locking type3-Side 7 mm, Key lock
-
Impact resistance IKIK10
Equipment
-
Number of section in width0
-
Number of flange plate openings2
-
Number of rows4
Installation, mounting
-
Mounting onWall mounting
-
Suitable for outdoor usageNo
Materials
-
ColourLight grey
-
RAL code7035
-
TreatmentPowder coated
-
MaterialSteel
Cover, door
-
Number of cabinet doors1
-
Door/cover is transparentYes
Electric current
-
Rated current250 A
Environmental value
We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers Learn More
Certifications and documents
Downloads
-
Product image
-
BIM Revit objects
Range : Orion Plus.Enclosure - IP65 - Class I - Steel enclosure - Depth 200 mm - English - Hosted family - REVIT Family 2020 - V2022
BIM Revit objects en-GB 2024-03-22
RFA1,34 MB
Range : Orion Plus.Enclosure - IP65 - Class I - Steel enclosure - Depth 200 mm - English - Non hosted family - REVIT Family 2020 - V2022
BIM Revit objects en-GB 2024-03-22
RFA1,41 MB
