Remote Control Dimmer universal 500W EVN002
EAN
3250617573931
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Architecture
-
Type of orderPush button
Configuration
-
Number of modules2
Main electrical features
-
Rated operational voltage Ue230 V
Voltage
-
Operating voltage230 V~ +10%/-15%
Fuse
-
Fusewith electronic short-circuit and overload protection
Dimensions
-
Depth of installed product62 mm
-
Height of installed product85 mm
-
Installation height0 / 1000 m
-
Width of installed product35 mm
-
Width of rail mounted device (RMD)2 modules
Length
-
Max distance to switches50 mm
Power
-
Dimmable conventional transformers500 VA
-
Halogen switching capacity 230V500 W
-
Power consumed4.5 W
-
Power consumption (operation)4.5 W
-
Power consumption (standby)0.2 W
-
Incandescent bulb power500 W
-
Total power loss under IN0.2 W
-
Conventional transformers500 VA
-
Electronic transformers500 W
Cover, door
-
Surface coverOther
Materials
-
Surface appearancematt
Fluorescent bulbs control
-
Dimmable energy-saving lamps100 W
-
Lighting power fluocompact lamps with built-in ballast100 W
LED control
-
Quantity of dimmable, 230 V retrofit LED lampsmax. 10
-
Max number of LED/CFL lamps10
-
Dimmable 230 V LED lamps100 W
-
Power LED100 W
Incandescent bulbs control
-
Max. power with incandescent lamps500 W
-
230 V incandescent lamps and halogen lamps500 W
Installation, mounting
-
Mounting typedin-Rail
-
Installation modefor mounting on DIN rail
Connection
-
Connection cross-sect. flexible conductor1,5 / 6mm²
-
Connection cross-sect. rigid cable1,5 / 6mm²
-
Type of loaduniversal
-
Conductor cross-section (flexible)1.5…6 mm²
-
Conductor cross-section (rigid)1.5…6 mm²
-
Type of connectionwith screw terminals
-
ConnectionConnection for non-illuminated push-buttons
Cable
-
Load cable lengthmax. 50 m
Equipment
-
Type of dimmerNo
-
Dimming principleautomatic load detection
Safety
-
REACH conformNo
-
RoHS conformYes
-
Halogen freeNo
Use conditions
-
Operating temperature-20…50 °C
-
Storage/transport temperature-20…50 °C
Instructions
-
Information textOnly for use with dimmable lamps!
