Obsolete
Remote control dimmer universal 1000W EV100
EAN
3250612421008
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
This product is unfortunately no longer available. Please contact our Customer Service team on 1300 850 253 for more information. We do have alternative solution that may be suitable
Technical properties
Voltage
-
Rated operational voltage Ue230 - 230 V
Frequency
-
Frequency50 - 50 Hz
Materials
-
ColourGrey
-
RAL code7035
Dimensions
-
Height85 mm
-
Width88,50 mm
-
Depth65 mm
Power
-
Power consumption during operation15 VA
-
Power consumption standby3 W
-
Power incandescent lamp20 - 1000 W
Use conditions
-
Operating temperature-10 - 45 °C
Connection
-
Cross-section rigid conductor1.5 - 10 mm²
-
Cross-section flexible conductor1 - 16 mm²
Capacity
-
Number of modules5
Texts
-
Dimming principleAutomatic load detection
-
Installation modeFor mounting on DIN rail
-
Type of connectionWith screw terminals
-
JunctionConnection for illuminated (max. 5 mA) or standard push-buttons
Environmental value
We are committed to improve our environmental performance by reducing our carbon footprint. Learn More
Certifications and documents
Downloads
-
Product image
-
Installation manual
Installation manual en-GB, fr-FR, de-DE, nl-NL 2017-09-11
PDF1,65 MB -
Declaration of conformity
Declaration
Declaration of conformity International 2020-02-07
PDF108,61 kB
