15A SINGLE SWITCHED SOCKET, Elegant Gold WGDS115SEG

EAN-Nr.
3250617279123
Packaging
8 Pieces

You have to log in with your myHager profile to see prices and to order.

Add to a list
Add to a list

Login to create a product list

You need to be logged into your myHager account to create product lists

Create an account Sign in

15A SINGLE SWITCHED SOCKET, Elegant Gold

WGDS115SEG

  • Accessories
  • Technical characteristics
  • Environmental value
  • Documentations
  • More products

Complete your system

Compatible products

  • Referenced by 4 products available

Referenced by

  • WGDCH2EG

    2G multi-gang frame;eg
    0.00 €  / *
  • WGDCH3EG

    3G multi-gang frame;eg
    0.00 €  / *
  • WGDCH4EG

    4G multi-gang frame;eg
    0.00 €  / *
  • WGDCH5EG

    5G multi-gang frame;eg
    0.00 €  / *

Technical characteristics

Elec­tric current
  • Rated current
    15 A
  • Output current
    0
Voltage
  • Rated voltage
    250 V
  • Nominal voltage
    220-250 V
  • Output voltage
    0-0 V
Frequency
  • Frequency
    50 - 60 Hz
Power
  • Output power
    0
  • Power consump­tion standby
    0
Mater­ials
  • Colour
    Gold
  • Surface finish
    Matt
  • Material
    Polycar­bonate (PC)
  • Treat­ment
    Coated
  • Contains recycled material (% of total plastic weight)
    0
Dimen­sions
  • Height
    30 mm
  • Width
    86 mm
  • Depth
    22 mm
  • Built-in depth flush-­mounted boxes
    35 mm
  • Built-in depth
    22 mm
Connec­tion
  • Connect­or/plug type
    British Standard
  • Cross-sec­tion flex­ible conductor without wire end sleeve
    0,08 - 4 mm²
Install­a­tion, mounting
  • Mounting on
    Flush mounting
  • Mount­ing-/­Con­nec­tion Posi­tion
    Back
Connectivity
  • Type of connec­tion
    Screw terminal
  • With claw mounting
    No
  • Mounting type
    Screw mounting
  • Connect­or/plug type USB
    British Standard
Equip­ment
  • Connect­or/plug type socket outlet
    British Standard
  • Rotated central insert
    No
  • With hinged lid
    No
  • With round protective earth pin
    No
  • With signal lamp
    No
  • With lock
    No
Accessories
  • Has labelling field
    No
  • Pre-equipped with
    None
Capa­city
  • Number of modules
    0
Safety
  • With enhanced contact protec­tion
    No
  • Impact resist­ance IK
    IK02
  • Ingress Protec­tion (IP) class
    IP20
Func­tions
  • With orient­a­tion lighting
    No
  • With func­tion lighting
    No
Iden­ti­fic­a­tion
  • With imprint
    No
  • Related Systems
    shark

Environmental value

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

RoHS conform Yes
REACh-SVHC free Yes
Halogen free Yes

Certifications and documents

Socket-outlet 2-gang Wago plug/clamp technique C-Profile in traffic white
PDF
48,73 MB
Hager REACH declaration WGDS115SEG
PDF
Hager RoHS report WGDS115SEG
PDF

Downloads

  • Image WGDS115SEG | Hager

    Product Image WGDS115SEG

  • Installation manual

    Image Installation manual en-GB 2024-09-26 | Hager

    Installation manual en-GB 2024-09-26

    PDF
    315,86 kB

  • Flyer

    Image Dream selection chart | Hager

    Dream selection chart

    Flyer en-GB 2023-04-04

    PDF
    429,29 kB

  • Catalogue

    Image Dream catalogue | Hager

    Dream catalogue

    Catalogue en-GB 2025-11-12

    PDF
    6,77 MB

  • Declaration of conformity

    Image BOC_CE_CERT_ALU-B_IT_EN_28102022 | Hager

    BOC_CE_CERT_ALU-B_IT_EN_28102022

    Declaration of conformity en-GB 2022-12-29

    PDF
    91,93 kB
