Presence detector 360° monobloc KNX with switch ON/OFF , white TCC520E

EAN-Nr.
3250617579407
Packaging
1 piece

You have to log in with your myHager profile to see prices and to order.

Add to a list
Add to a list

Login to create a product list

You need to be logged into your myHager account to create product lists

Create an account Sign in

Presence detector 360° monobloc KNX with switch ON/OFF , white

TCC520E

  • Accessories
  • Technical characteristics
  • Environmental value
  • Documentations
  • More products

Complete your system

Optional accessories

  • Accessor­ies/s­pare parts for move­ment sensor 1 products available

Complete your system

  • Accessor­ies/s­pare parts for move­ment sensor
  • EE808

    Remote control for customer for presence detectors 360° monobloc
    0.00 €  / *

Technical characteristics

Dimen­sions
  • Install­a­tion height
    4 - 4 m
  • Recom­mended install­a­tion height
    2,5 - 3,5 m
Settings
  • Supported config­ur­a­tion mode
    ETS
  • Minimal duty cycle
    60 s
Func­tions
  • Maximal duty cycle
    60 min
Connectivity
  • With bus system KNX radio
    No
Voltage
  • Oper­ating voltage over bus
    21 - 32 V
Scope of delivery
  • Bus connec­tion included
    Yes
Elec­tric current
  • Bus current consump­tion data transfer
    12 mA
Detec­tion
  • Detec­tion angle
    360 - 360
  • Detec­tion angle hori­zontal
    360 - 360
Use condi­tions
  • Oper­ating temper­ature
    -10 - 45 °C
Mater­ials
  • Material
    Acryloni­trile-Butadiene-Styrene (ABS), Polycar­bonate (PC)
Texts
  • Oper­ating mode
    Oper­ating modes: auto­matic, semi­auto­matic, test
  • Func­tion
    Linking several detectors in order to expand the detec­tion area
  • Install­a­tion mode
    With spring clips for ceiling install­a­tion

Environmental value

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

RoHS conform Yes

Certifications and documents

Hager REACH declaration TCC520E
PDF
RoHS report TCC520E
PDF

Downloads

  • Image TCC520E | Hager

    Product Image TCC520E

  • Installation manual

    Image Installation manual en-GB, es-ES, it-IT, pt-PT 2019-08-23 | Hager

    Installation manual en-GB, es-ES, it-IT, pt-PT 2019-08-23

    PDF
    329,60 kB
    Image Installation manual en-GB, fr-FR, de-DE, nl-NL 2019-08-23 | Hager

    Installation manual en-GB, fr-FR, de-DE, nl-NL 2019-08-23

    PDF
    319,52 kB
    Image Installation manual en-GB, fr-FR 2019-10-24 | Hager

    Installation manual en-GB, fr-FR 2019-10-24

    PDF
    276,21 kB

  • KNX product database

    Image Logiciel d'application ETS du TCC520E | Hager

    Logiciel d'application ETS du TCC520E

    KNX product database da-DK, en-GB, es-ES, fr-FR, de-DE, it-IT, nl-NL, pl-PL, pt-PT 2020-01-01

    KNXPROD
    128,30 kB
    Image Logiciel d'application ETS du TCC520E | Hager

    Logiciel d'application ETS du TCC520E

    KNX product database da-DK, en-GB, es-ES, fr-FR, de-DE, it-IT, nl-NL, pl-PL, pt-PT 2020-01-01

    VD5
    145,53 kB

  • Application Guide

    Image Description d'application ETS TCC520E | Hager

    Description d'application ETS TCC520E

    Application Guide en-GB, pl-PL 2013-03-18

    PDF
    2,24 MB

  • Declaration of conformity

    Image Declaration of conformity International 2022-11-08 | Hager

    Declaration of conformity International 2022-11-08

    PDF
    143,55 kB
