Bell transformer 8VA 230V 8-12V ST303
EAN-Nr.
3250615703033
Packaging
6 Pieces
Login to create a product list
You need to be logged into your myHager account to create product lists
Stop delivery w sub Example text: This product is now obsolete. However, you can view the following products as replacements or extensions. As the functions of the replacement product are not absolutely identical, please consult your nearest Hager partner if you have any questions.
Technical characteristics
Voltage
-
Output voltage8 - 12 V
-
Rated operational voltage Ue230 - 230 V
-
Output voltage 212 V
-
Rated insulation voltage Ui4000 V
Capacity
-
Number of modules2
Power
-
Total power loss under IN2,20 W
-
Power consumption VA8 VA
-
Power8 VA
-
Power absorbed8 W
Dimensions
-
Height111 mm
-
Width35 mm
-
Depth65 mm
Safety
-
Ingress Protection (IP) classIP20
-
Temperature protectionYes
Equipment
-
Is short-circuit protectedYes
-
On/off switchNo
Use conditions
-
Operating temperature-20 - 35 °C
Connection
-
Cross-section flexible conductor4 mm²
-
Cross-section rigid conductor6 mm²
Frequency
-
Frequency50 - 50 Hz
Electric current
-
Intensity output 11 A
-
Intensity output 20,67 A
-
Max. intensity of secondary1 A
Installation, mounting
-
Mounting onDIN rail
-
Nominal tightening torque1,20 - 1,20 Nm
Internal use only
-
Number of half modules of 17,5 mm4
Compatibility
-
Suitable for DIN RailYes
