Ammeter switch 3 O SK603
EAN-Nr.
3250615616036
Packaging
1 piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Stop delivery w sub Example text: This product is now obsolete. However, you can view the following products as replacements or extensions. As the functions of the replacement product are not absolutely identical, please consult your nearest Hager partner if you have any questions.
Technical characteristics
Electric current
-
Rated current20 A
Capacity
-
Number of modules3
Frequency
-
Frequency50 - 50 Hz
Use conditions
-
Operating temperature-10 - 40 °C
-
Storage/transport temperature-40 - 80 °C
Connectivity
-
Type of connectionScrew terminal
Connection
-
Cross-section flexible conductor1.5 - 10 mm²
-
Cross-section rigid conductor1 - 6 mm²
Power
-
Total power loss under IN1 W
Dimensions
-
Height85 mm
-
Width70 mm
-
Depth64 mm
Safety
-
Ingress Protection (IP) classIP20
Voltage
-
Rated insulation voltage Ui690 V
Installation, mounting
-
Mounting onDIN rail
Architecture
-
Type of pole3P+N
Equipment
-
With batteryNo
