Steel enclosure, Orion.Plus, glazed door 350x300x160 mm FL154A
EAN-Nr.
3250610670651
Packaging
1 piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Cover strip 1 products available -
Lock system 4 products available -
Mounting accessories 3 products available -
Accessories/spare parts for earthing and lightning 1 products available -
Insert for lock system 3 products available -
Distributor assembly for serial built-in device 1 products available
Complete your system
Technical characteristics
Dimensions
-
Height350 mm
-
Width300 mm
-
Depth160 mm
-
Thickness of sidewall1,20 mm
Safety
-
Ingress Protection (IP) classIP65
-
Protection classIsolation class I
-
Locking type3-Side 7 mm, Key lock
-
Impact resistance IKIK10
Equipment
-
Number of section in width0
-
Number of flange plate openings2
-
Number of rows2
Installation, mounting
-
Mounting onWall mounting
-
Suitable for outdoor usageNo
Materials
-
ColourLight grey
-
RAL code7035
-
TreatmentPowder coated
-
MaterialSteel
Cover, door
-
Number of cabinet doors1
-
Door/cover is transparentYes
Electric current
-
Rated current250 A
Environmental value
We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More
Certifications and documents
Downloads
-
Installation manual
Instruction sheet
Installation manual International 2020-11-10
PDF32,87 MB -
Declaration of conformity
EU Declaration of Conformity_24.3441.06.24
Declaration of conformity en-GB 2024-06-26
PDF254,37 kB
UKCA Declaration of Conformity_24.3313.06.24
Declaration of conformity en-US 2024-06-26
PDF259,47 kB
