RCBO 4P 6kA C-40A 30mA A Class ADM490G

Name: ADM490G
Brand: Hager
SKU: ADM490G

EAN-Nr.

3250611028727

Packaging

1 piece

Only available for Singapore

Accessories
Technical characteristics
Environmental value
Documentations
More products

Complete your system

Modular phase busbar 3 products available
Locking interlocking functions 1 products available
Mechanic accessories for low-voltage components 1 products available
Under voltage coil 2 products available
Shunt release 2 products available
Auxiliaries contact block 2 products available

Technical characteristics

Rated current

40 A
Rated residual operating current Idn

30 mA
Rated short-circuit breaking capacity Icn under 400 V AC according to IEC 60898-1

6 kA
Rated current -25°C

49,80 A
Rated current at -20°C

49 A
Rated current -15°C

48,20 A
Rated current -10°C

47,30 A
Rated current -5°C

46,50 A
Rated current at 0°C

45,60 A
Rated current 5°C

44,70 A
Rated current 10°C

43,80 A
Rated current 15°C

42,90 A
Rated current at 20°C

42 A
Rated current 25°C

41 A
Rated current 30°C

40 A
Rated current 35°C

38,90 A
Rated current at 40°C

37,70 A
Rated current at 45°C

36,50 A
Rated current at 50°C

35,20 A
Rated current 55°C

33,90 A
Rated current 60°C

32,60 A

Curve

C
Neutral position

Left, Right
Type of pole

4P
Number of protected poles

4

Number of modules

4

Residual current type

A
Ingress Protection (IP) class

IP20

Type voltage supply

AC
Rated operational voltage Ue

230 - 400 V
Rated insulation voltage Ui

500 V
Dielectric strength value of power frequency

2 kV
Rated impulse withstand voltage Uimp

4000 V
Overvoltage category according to IEC 60947-1

3

Nominal tightening torque top terminal

2 - 2 Nm
Nominal tightening torque down terminal

2 - 2 Nm
Nominal tightening torque

2 - 2 Nm
360° mounting position possible

Yes
Type of top connection for modular devices

Screw terminal
Type of bottom connection for modular devices

biconnect

Rated short-circuit breaking capacity Icn AC according to IEC 60898-1

6 kA

Frequency

50 - 50 Hz

Cross-section of input with screws, for flexible conductors

1 - 16 mm²
Cross-section of input with screws, for massive conductors

1 - 25 mm²

Class of energy limitation I²t

3
Operating temperature

-25 - 40 °C

Height

84 mm
Width

71 mm
Depth

70 mm

Type of connection

Screw terminal

Total power loss under IN

17,70 W

Environmental value

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

RoHS conform Yes
