RCBO 1M 1P+N 6kA C-6A 30mA typ A ADC906R

No longer available

Accessories
Technical characteristics
Environmental value
Documentations

Download the sheet

Complete your system

Locking interlocking functions 1 products available

Technical characteristics

Type of pole

1P+N
Number of protected poles

1
Curve

C

Rated current IN

6 A
Rated residual operating current Idn

30 mA
Rated current -25°C

7,40 A
Rated current at -20°C

7,30 A
Rated current -15°C

7,10 A
Rated current -10°C

7 A
Rated current -5°C

6,90 A
Rated current at 0°C

6,80 A
Rated current 5°C

6,60 A
Rated current 10°C

6,50 A
Rated current 15°C

6,40 A
Rated current at 20°C

6,30 A
Rated current 25°C

6,10 A
Rated current 30°C

6 A
Rated current 35°C

5,90 A
Rated current at 40°C

5,70 A
Rated current at 50°C

5,50 A
Rated current 55°C

5,40 A
Rated current 60°C

5,20 A
Min./max. threshold value of the AC thermal operation

1,13 - 1,45 A

Residual current type

A
Ingress Protection (IP) class

IP20

Rated short-circuit breaking capacity Icn AC according to IEC 60898-1

6 kA

Rated insulation voltage Ui

440 V
Rated impulse withstand voltage Uimp

4000 V
Max. operating voltage

264 V
Rated operational voltage Ue

230 - 230 V
Overvoltage category according to IEC 60947-1

3

Power dissipation at IN

2,74 W

Frequency

50 - 50 Hz

Max. altitude

2000 m
Class of energy limitation I²t

3
Operating temperature

-25 - 70 °C
Storage/transport temperature

-25 - 80 °C

Cross-section of input with screws, for flexible conductors

1 - 10 mm²
Cross-section of input with screws, for massive conductors

1 - 16 mm²
Cross-section of input and output with screws, for flexible conductors

1 - 10 mm²
Cross-section of input and output with screws, for massive conductors

1 - 16 mm²
Cross-section of output with screws, for flexible conductors

1 - 10 mm²
Cross-section of output with screws, for massive conductors

1 - 16 mm²

Type of top connection for modular devices

Screw terminal
Type of bottom connection for modular devices

biconnect

Number of modules

1

Height

85 mm
Width

17,70 mm
Depth

70 mm

Suitable for DIN Rail

Yes
