Bell 230V SU213
EAN
3250615712134
Packaging
12 PCEs
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Functions
-
Mode of operationSound signal : type D - duration of intermittent operation recommended : 5s ON / 15s OFF
Configuration
-
Number of modules1
Main electrical features
-
Rated operational voltage Ue230 V
-
Type of supply voltageAC
Electric current
-
Operating current0.03 A
-
Rated current0.03 A
Dimensions
-
Depth of installed product65 mm
-
Height of installed product80 mm
-
Width of installed product18 mm
Frequency
-
Frequency50 to 0 Hz
Power
-
Power consumed6.5 VA
-
Total power loss under IN6.5 W
Materials
-
Materialpolyamide
Connection
-
Connection cross-sect. flexible conductor4mm²
-
Connection cross-sect. rigid cable6mm²
Equipment
-
Noise level85 dB
Use conditions
-
Operating temperature-10…40 °C
-
Storage/transport temperature-25…60 °C
