Mini-enclosure, GD, 2 module wide, protect. class IP30, without door GD102T
EAN
3250612846504
Packaging
10 PCEs
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Configuration
-
Number of modules2
Main electrical features
-
Nominal voltage230 V
Electric current
-
Rated current32 A
Dimensions
-
Depth of installed product82 mm
-
Internal depth82 mm
-
Height of installed product160 mm
-
Width of installed product55 mm
-
Width in division units2
Cover, door
-
Type of door closingnon keylock
-
Cover typeWith Notch
-
Door lockingwithout
-
Cover typewith notch
-
Transparent cover or doorNo
Materials
-
Colourwhite
-
Colourwhite
-
RAL colourRAL 9010 - Pure white
-
Materialplastic
Settings
-
Enclosure typeDistributor empty cabinet
Equipment
-
Number of rows1
-
Quantity of rails1
-
Can be accessorizedNo
-
Earthing terminal blockNo
-
Neutral terminal blockNo
Standards
-
European directive WEEEnot concerned
Safety
-
IK protection code against mecanical impacts05
-
Protection classisol.class II
-
Halogen freeNo
