RCBO Electronic 1P 6kA C-6A 30mA A Class 1M ADC306T

Name: ADC306T
Brand: Hager
SKU: ADC306T5

EAN

3250611010289

Packaging

1 Piece

Complete your system

Rated current

6 A
Rated residual operating current Idn

30 mA
Rated current -25°C

9,16 A
Rated current at -20°C

8,92 A
Rated current -15°C

8,69 A
Rated current -10°C

8,64 A
Rated current -5°C

8,21 A
Rated current at 0°C

7,98 A
Rated current 5°C

7,74 A
Rated current 10°C

7,51 A
Rated current 15°C

7,27 A
Rated current at 20°C

7,04 A
Rated current 25°C

6,80 A
Rated current 30°C

6 A
Rated current 35°C

6,33 A
Rated current at 40°C

6,10 A
Rated current at 50°C

6 A
Rated current 55°C

5,39 A
Rated current 60°C

5,15 A
Correction factor of rating current for 2 devices placed side by side

0,95
Correction factor of rating current for 3 devices placed side by side

0,95
Correction factor of rating current for 4 and 5 devices placed side by side

0,90
Correction factor of rating current for 6 devices placed side by side

0,85
Min./max. threshold value of the AC thermal operation

1,13 - 1,45 A
