Combined SPD T1+T2 1P Iimp 25kA Up 1.5kV with remote contact integrated fuse SPA180
EAN-Nr.
3250615515056
Packaging
1 piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Stop delivery w sub Example text: This product is now obsolete. However, you can view the following products as replacements or extensions. As the functions of the replacement product are not absolutely identical, please consult your nearest Hager partner if you have any questions.
Technical characteristics
Electric current
-
Max. discharge (Imax) L-N(PEN)/ N-PE50 kA
-
Lightning impulse current Iimp (10/350 µs) IEC 61643 L-N(PEN)/ N-PE25 kA
Network configuration
-
Network typeTN-S, TT
Connectivity
-
Type of connectionScrew terminal, Plug-in connection
Equipment
-
With remote signalling contactYes
Capacity
-
Number of modules2
Voltage
-
Voltage protection level Up according to IEC 61643-11,50 kV
-
Continuous operating voltage Uc according to IEC 61643-1264 V
-
Rated operational voltage Ue240 - 240 V
-
Voltage level Up L-N/PEN IEC 61643-111,5 kV
Architecture
-
Number of poles1
Use conditions
-
Operating temperature-40 - 80 °C
Dimensions
-
Height167 mm
-
Width35,50 mm
-
Depth74,5 mm
Controls and indicators
-
With indicator lampYes
Standards
-
Requirement class IEC 61643T1, T2
Installation, mounting
-
Nominal tightening torque4,50 - 4,50 Nm
Connection
-
Cross-section of input and output with screws, for flexible conductors35 - 35 mm²
-
Cross-section of input and output with screws, for massive conductors35 - 35 mm²
-
Cross-section signal contact0,14 - 1,5 mm²
Frequency
-
Frequency50 - 60 Hz
Safety
-
Ingress Protection (IP) classIP20
