Reverser 2O 2F SK601

EAN-Nr.
3250615616012
Packaging
1 piece

You have to log in with your myHager profile to see prices and to order.

Add to a list
Add to a list

Login to create a product list

You need to be logged into your myHager account to create product lists

Create an account Sign in

Reverser 2O 2F

SK601

  • Technical characteristics
  • Environmental value
  • Documentations
  • More products

Technical characteristics

Archi­tec­ture
  • Number of poles
    2
  • Type of pole
    2P
Elec­tric current
  • Rated current
    20 A
  • Rated condi­tional short-­cir­cuit current Icc with gl-gG fuses
    8 kA
Voltage
  • Rated oper­a­tional voltage Ue
    660 - 660 V
  • Type voltage supply
    AC
  • Rated insu­la­tion voltage Ui
    690 V
Capa­city
  • Number of modules
    3
Safety
  • Ingress Protec­tion (IP) class
    IP20
Frequency
  • Frequency
    50 - 50 Hz
Dimen­sions
  • Height
    85 mm
  • Width
    53 mm
  • Depth
    64 mm
Equip­ment
  • Number of NO contacts
    2
  • Number of NC contacts
    2
Use condi­tions
  • Oper­ating temper­ature
    -10 - 40 °C
  • Stor­age/trans­port temper­ature
    -40 - 80 °C
Connec­tion
  • Cross-sec­tion flex­ible conductor
    1.5 - 10 mm²
  • Cross-sec­tion rigid conductor
    1 - 6 mm²

Environmental value

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

RoHS conform Yes
REACh-SVHC free Yes

Certifications and documents

Hager REACH declaration SK601
PDF
Hager RoHS report SK601
PDF

Downloads

  • Image SK601 | Hager

    Product Image SK601

  • Declaration of conformity

    Image Declaration of conformity for Inverter / Switch | Hager

    Declaration of conformity for Inverter / Switch

    Declaration of conformity International 2021-10-13

    PDF
    133,67 kB
    Image Declaration of conformity for Inverter / Switch | Hager

    Declaration of conformity for Inverter / Switch

    Declaration of conformity International 2019-11-04

    PDF
    115,04 kB
