Auxiliary contact for centralised control EPN050
EAN-Nr.
3250612360543
Packaging
1 piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Compatible products
-
Referenced by 10 products available
Referenced by
-
EPN526Latching relay 2NO 48V
-
EPN503Latching relay 1NO+1NC 48V
-
EPN525Latching relay 2NC+2NO 230V
-
EPN520Latching relay 2NO 230V
-
EPN524Latching relay 2NO 24V
-
EPN510Latching relay 1NO 230V
-
EPN513Latching relay 1NO 24V
-
EPN515Latching relay 1NC+1NO 230V
-
EPN518Latching relay 1NC+1NO 24V
-
EPN540Latching relay 4NO 230V
Technical characteristics
Electric current
-
Rated current1 A
Capacity
-
Number of modules0,50
Use conditions
-
Operating temperature-5 - 40 °C
-
Storage/transport temperature-40 - 80 °C
Connectivity
-
Type of connectionScrew terminal
Connection
-
Cross-section flexible conductor1 - 6 mm²
-
Cross-section rigid conductor1.5 - 10 mm²
Power
-
Total power loss under IN0,10 W
Dimensions
-
Height85 mm
-
Width8,90 mm
-
Depth58 mm
