B.IQ push-button 4gang comf, KNX - B.IQ, glass p. white 75164590
EAN-Nr.
4011334380894
Packaging
1 piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Must-have accessories
75040001
Bus coupling unit flush-mtd, KNX
Optional accessories
-
Labelling material for domestic switching devices 1 products available
Technical characteristics
Installation, mounting
-
Mounting onFlush mounting
Use conditions
-
Operating temperature-5 - 45 °C
Functions
-
With room temperature controllerNo
Dimensions
-
Height118,10 mm
-
Width88,50 mm
-
Depth16,65 mm
Equipment
-
Number of actuation points8
Controls and indicators
-
With LED indicationYes
Materials
-
ColourPolar white
-
RAL code9010
-
MaterialGlass
-
Surface finishGlossy
Accessories
-
Has labelling fieldNo
Screen
-
With displayNo
Texts
-
FunctionFor switch, push-button, dimmer and shutter functions
-
ProtectionWith dismantling protection
Environmental value
We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More
Certifications and documents
Downloads
-
Installation manual
Manual for 751615xx-751625xx-751635xx-751645xx - B.IQ push-button 1gang comfort (DE-EN-NL-NO-ES, 2021-12)
Installation manual International 2004-04-20
PDF400,23 kB -
Declaration of conformity
Declaration of Conformity
Declaration of conformity International 2021-03-05
PDF258,49 kB
Declaration of Conformity
Declaration of conformity International 2021-03-05
PDF258,73 kB
