Touch sensor, 4-gang comf, intg bus coupling unit, KNX - R.1, glass p. white 75144860
EAN-Nr.
4011334383505
Packaging
1 piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Must-have accessories
Compatible products
-
Referenced by 1 products available
Technical characteristics
Installation, mounting
-
Mounting onFlush mounting
Use conditions
-
Operating temperature-5 - 45 °C
Functions
-
With room temperature controllerYes
Power
-
Current consumption12,50 mA
Dimensions
-
Built-in depth12,90 mm
-
Built-in depth flush-mounted boxes16 mm
-
Height152 mm
-
Width81 mm
-
Depth23 mm
Equipment
-
Number of actuation points8
Controls and indicators
-
With LED indicationYes
Materials
-
ColourPolar white
-
RAL code9010
-
MaterialGlass
-
Surface finishGlossy
Accessories
-
Has labelling fieldNo
Screen
-
With displayYes
Texts
-
FunctionFor switch, push-button, dimmer and shutter functions, Blocking function for sensor surface e.g. for cleaning the glass surface
-
Installation modeFor vertical mounting
-
TemperatureAdditional connection for external temperature sensor, Integrated temperature sensor for operation as controller extension unit, Temperature measurement via internal Temperature sensor or external communication object
Environmental value
We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More
Certifications and documents
Downloads
More documentation
